Advantages Overview
Twin Screw pumps are setting a new standard for sanitary design. The mechanical seals are fully exposed to 100% of the passing CIP liquid and the pump is 100% drainable by design. There are almost no limitations in media viscosity, pumping product from water to silicone at discharge pressures from 230 to 360 psi. With dual mechanical seals, the pumps can run dry for extended periods. It primes low viscous media up to 3 feet and operates with extremely high suction at an NPSH of 3 to 4 feet. It does not get airborne ever. The pump is fully by-directional at max pressure range.
- Because product is moved axially to the shaft, it can operate at low speed for high viscous product and very high speed for low viscous media, making it a perfect CIP return pump that never gets airborne.
- The pump is fully bi-directional by design.
- The pump has a higher tolerance for debris and abrasive media than most other pump designs.
- The pump does not “pinch” soft items at the inlet or discharge, simply moves it though the screw channels without size restriction.
- Largest viscosity range from
- It generates almost no pulsation, so it makes an excellent dosing pump.
- Very low wear and tear compared to other high viscous pumps.
- Safe to run dry for extended periods of time when using water flushed seals due to non-touching metal-to-metal rotor design.
- Can gently pump sensitive media because of the axial flow design.
- Pumps media with gas content up to 60% without issues.
- Product lift capability up to 4 feet.
- Excellent speed control characteristics compared to Rotary Lobe Pumps.
- Large temperature span with standard configuration up to 266F.
- Pump heads can be installed in serial arrangement without bypass valves.
- Particulate sizes up to 1-1/2” Inches.
- Excellent wear and tear resistance and high tolerance for debris.
- Can be installed sideways and upside down with small bearing frame adjustments.
- Heat jacketed pump heads provide a larger heating surface compared to other pump systems.
